Vulcan MSA36 36" Heavy Duty Gas Griddle, Countertop

Mfg Part Number:
MSA36
Manufacturer:
Vulcan
In stock
SKU
241196
Case Pack: 1EA
Special Order


The Vulcan MSA36 Heavy Duty Gas Griddle is a part of the MSA Series of Vulcan Gas Griddles. The design is constructed of stainless steel on the back, sides and front. The front features a "Cool Bullnose" design that helps to distribute the griddle heat before coming to the edge. The frame is fully welded stainless and aluminized steel and constructed to provide a low cooking height of 11" on 4" adjustable legs. A 3-1/2" spatula-wide grease chute is fully welded for easy cleanup and to decrease grease migration. A large 6 quart, stainless steel, grease drawer takes the grease from off of the griddle. This griddle comes with three "U" shaped aluminized steel burners, each providing 27,000 BTU

Heavy Duty Griddle, countertop, gas, 36" W x 24" D cooking surface, 1" thick polished steel griddle plate, embedded mechanical snap action thermostat every 12", millivolt pilot safety, manual ignition, low profile, stainless steel front, sides, front grease trough, 4" back & tapered side splashes, 4" adjustable legs, 81,000 BTU, CSA Star, CSA Flame, NSF

Specifications

More Information
Manufacturer Vulcan
Sales Unit EA
Griddle Width 36 Inches
Operation Heavy Duty
BTU Per Burner 27000
Burner Style U-Shape
Certification(s) CSA Design Certified, NSF Listed
# of Controls 3
Cooking Surface 36"W x 24"D
Cooking Surface Material Polished steel
Depth 21-33-Inches
Product Dimensions 36"W x 31-1/2"D x 15-1/4"H
Gas Connection 3/4" rear connection with gas pressure regulator
Plate Thickness 1"
Total BTU 81000
Product Weight 400 Lbs
Warranty Unit is backed by a 1-Year Parts & Labor Warranty.
Control Type Thermostatic
Material Stainless Steel
Power Type Natural Gas
Shipping Weight 400.00 lbs
